1. Package: wood drum
2. Certificate: CE ROHS ETL UL CPR
3. Free samples
4. Provide test report
5. Stable quality, complete testing equipment
Optical cables are mainly used in the transmission of optical signals in telecommunications networks
Temperature Range
| Transport/Storage Temp | Installation Temp | Operation Temp |
| -40℃~+70℃ | -30℃~+50℃ | -40℃~+70℃ |
| Fiber Count | 2~48 |
| Loose Tube | Colored Fiber In Pbt Loose Tube, Filled With Fiber Gel |
| Strength Member | Two Parallel Steel Wires |
| Corrugated Steel-Plastic Tape | Ensures Nice Moisture Proof And Side Pressure Resisting Capability Of Cable. |
| Sheath | Polyethylene(PE) |
| Fiber Count | Cable Outer Dia (Mm) | Cable Weight (Kg/Km) | Min.Bending Radius(Mm) | Permissible Tensile Force（n） | Permissible Pressure Force（n/100mm） | |||
| Static | Dynamic | Short Term | Long Term | Short Term | Long Term | |||
| 2-12 | 8 | 70 | 10d | 20d | 1500 | 600 | 1000 | 600 |
| 14-24 | 8.7 | 81 | 10d | 20d | 1500 | 600 | 1000 | 600 |
| 26-36 | 9.4 | 95 | 10d | 20d | 1500 | 600 | 1000 | 600 |
| 38-48 | 10 | 106 | 10d | 20d | 1500 | 600 | 1000 | 600 |
| Note："d" Is Cable Diameter | ||||||||
