1. Package: wood drum
2. Certificate: CE ROHS ETL UL CPR
3. Free samples
4. Provide test report
5. Stable quality, complete testing equipment
Optical cables are mainly used in the transmission of optical signals in telecommunications networks
| Transport/Storage Temp | Installation Temp | Operation Temp |
| -40℃~+70℃ | -30℃~+50℃ | -40℃~+70℃ |
| Fiber Count | 2~288 |
| Loose Tube | Colored Fiber In Pbt Loose Tube, Filled With Fiber Gel |
| Central Strength Member | Steel Wire Or Frp(Fiber Reinforce Plastic Rod) |
| Waterproof Layer | Cable Core Filled With Cable Gel Or Water Blocking Tape, Water Blocking Yarns |
| Sheath | Polyethylene(PE) |
| Fiber Count | Cable Outer Dia (Mm) | Cable Weight (Kg/Km) | Min.Bending Radius(Mm) | Permissible Tensile Force（n） | Permissible Pressure Force（n/100mm） | |||
| Static | Dynamic | Short Term | Long Term | Short Term | Long Term | |||
| 2-36 | 9.4 | 75 | 10d | 20d | 1500 | 600 | 1000 | 300 |
| 38-72 | 10 | 85 | 10d | 20d | 1500 | 600 | 1000 | 300 |
| 74-84 | 10.7 | 100 | 10d | 20d | 1500 | 600 | 1000 | 300 |
| 86-96 | 11.3 | 110 | 10d | 20d | 1500 | 600 | 1000 | 300 |
| 98-108 | 12 | 122 | 10d | 20d | 1500 | 600 | 1000 | 300 |
| 132-144 | 14 | 165 | 10d | 20d | 1500 | 600 | 1000 | 300 |
| 288 | 16.8 | 241 | 10d | 20d | 1500 | 600 | 1000 | 300 |
| Note："d" Is Cable Diameter | ||||||||
